Cold Rolled Oriented Silicon Steel Motor Core

Looking for high-quality Cold Rolled Oriented Silicon Steel Motor Core? Look no further! Our factory produces top-notch motor cores for various applications.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Certifications
  • Packaging & Shipping
  • Company Profile
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
UI Lamination
Usage
Single-phase Transformer, Rectifier Transformer, Combined Transformer, Power Transformer, Distribution Transformer
Frequency Characteristics
Power Frequency
Shape of Core
EI
Brand
Centersky
Product Name
High Quality Control Low Iron Ui Silicon Iron Cast
Thickness
0.23/0.27/0.3/0.35mm
Surface Treatment
Coated
Packing
RoHS
Standard
AISI, ASTM, GB, Other
Chemical Composition
Silicon Steel
Material
Cold Rolled Non-Oriented Silicon Steel
Key Words
Silicon Steel Sheet
Shape
Ei Lamination
Size
Inaternational Size
Transport Package
25kg/CTN; 40CTN/Pallet
Specification
customized size
Trademark
centersky
Origin
China
HS Code
85049019
Production Capacity
3000tons/Month

Product Description



Product Description



Are you looking for the HQ lamination silicon steel sheet?

Centersky is the silicon steel sheet producer for the worldwide electric reactor, electromotor, electric generator and transformer manufacturers.




    CENTERSKY is a manufacturer who produce single phase / three phase lamination: EI, UI, UT, 3PEI.etc. The thickness can be from 0.23-0.5mm,CRNGO and CRGO from famous steel factory.


    Three-phase EI core is made by the silicon steel strip. The models of EI lamination in standard sizes are from 3PEI-17.5 to 3PEI-120.The gap sizes of the transformer lamination core can be customized.


    Our high quality silicon steel laminations can be used in different kinds of products, such as transformersreactorsUPS, ballast resistorselectrical ballast and many other electrical products. Any comments are welcome.





 SIZE

 EI-35 to EI-360

 3PEI-17.5-3PEI-100

 THCIKNESS

 0.23-0.35MM (CRGO)

 0.35-0.5MM  (CRNGO)

 MATERIAL

 M3, M4, M5, M6 (CRGO)

 35W250, 35W300, 35W400 (0.35MM)

 50W250, 50W310, 50W400, 50W470, 50W600, 50W800 (0.5MM)

 FREQUENCY

 50HZ-60HZ

 COATING

 T2  Inorganic ( CRGO )

 T4  Semi-organic (CRNGO)

 PROCESS TECHNOLOGY

 ANNEALLING & WITHOUT ANNEALLING

 APPLICATION

 CONTROL TRANSFORMER, AUTO TRANSFORMER, ISOLATION TRANSFORMER,

 POWER TRANSFORMER; BALLAST, REACTOR,INDUCTOR,INVERTER POWER,

 VOLTAGE STABILIZERS.etc



Product Parameters

Cold Rolled Oriented Silicon Steel Motor Core

Type a b c d e holes aperture(Φ)
EI- 28 28 4 6 8 17
EI-35 35 5 7.5 10 19.5
EI-41 41 6 8 13 21
EI-42 42 7 7 7 14
EI-48 48 8 8 16 24
EI-50 50 8 9 16 25.5
EI-57 57 9.5 9.5 19 28.5 4 4
EI-60 60 10 10 20 30 4 5
EI-66 66 11 11 22 33 4 4
EI-76.2 76.2 12.7 12.7 25.4 38.1 4 5
EI-78 78 13 13 26 39 4 5
EI-84 84 14 14 28 41 4 6
EI-85.8 85.8 14.3 14.3 28.6 42.9 4 5
EI-96 96 16 16 32 48 4 6
EI-105 105 17.5 17.5 35 52.5 4 6
EI-108 108 18 18 36 54 4 5.5
EI-114 114 19 19 38 57 4 7
EI-120 120 20 20 40 60 4 7
EI-133.2 133.2 22.2 22.2 44.4 66.6 4 7
EI-150 150 25 25 50 75 4 8
EI-152.4 152.4 25.4 25.4 50.8 76.2 4 8
EI-162 162 27 27 54 81 4 10
EI-168 168 28 28 50 84 4 10
EI-171 171 28.5 28.5 57 85.5 4 10
EI-180 180 30 30 60 90 4 10
EI-192 192 32 32 64 96 4 10
EI-270 270 45 45 90 135 4 12
EI-228 228 38 38 76 114 4 10
EI-300 300 50 50 100 150 4 12
EI-360 360 60 60 120 180 4 12

Cold Rolled Oriented Silicon Steel Motor CoreCold Rolled Oriented Silicon Steel Motor Core
Cold Rolled Oriented Silicon Steel Motor Core

Certifications

Cold Rolled Oriented Silicon Steel Motor Core

Packaging & Shipping

Cold Rolled Oriented Silicon Steel Motor Core

Company Profile

Cold Rolled Oriented Silicon Steel Motor Core
    Our company has introduced a dozen of fully automatic high-speed precision punching presses and a hundred of other punching presses. The floor

area of the company is nearly 15,000 square meters. There are about 30 quality monitoring people among 200 employees. Over the past years, we

have insisted on the policy of "customer satisfaction" and constantly strived for improvement. Guided by the principle of "quality first", we attach great

importance to procedures and results.


Cold Rolled Oriented Silicon Steel Motor Core

Our Advantages


1, Advantage: Directly manufacturing factory with competitive price and quality control, we check all material when we start to bulk productions.

2, Professional advice to help you purchase the products you wanted

3, Professional export service team servers in the deal.

4, Customization service is available, OEM business is appreciated.

5, We will inspect and test all products material carefully to ensure no damage and lost.

6, The success of our cooperation can be guaranteed for our company is a credible and honest partner.



FAQ

1. Q: Can I get some samples?

A:Yes,sample order is available for quality check and market test.



2. Q: What's the delivery time?

A: Sample order needs 1-2 days. Formal order needs 7-12 days.



3. Q: What's your payment terms?

A: TT, LC, and DP.



4. Q: Do you have the prodcts in stock?

A:Yes,we will keep some general ones in stock.



5.Q: Can I mix different models in one container?

A: Yes, different models can be mixed up



6.Q:Will you deliver the right products as I ordered? How can I trust you?

A: Sure,we could accept trade assurance on Made-in-China, which will protect buyer's order.
